3D top hat made up, in four colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
What the classic pattern makes, seen from a little above and drawn in its own proportions: brim, crown, band and top. Each layer is one piece, so it also cuts as a flat top hat for a card or an invitation.
What is in the file
| Size | 100 × 77 mm (3.94 × 3.04 in), scales to any size |
|---|---|
| Pieces | 4 separate pieces |
| Outlines to cut | 4 outlines |
| Cut length | 736 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 64 curve and line segments |
| Layers | 4: brim, crown, band and top |
Measured from the file. PNG: 2,000 × 1,562 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.77 in (25 × 20 mm) | Over 1.5 mm | 187 mm | 120 | Vinyl, card and thin sheet |
| 2 × 1.54 in (51 × 39 mm) | Over 3 mm | 374 mm | 30 | Any material, including 3 mm wood and acrylic |
| 3 × 2.32 in (76 × 59 mm) | Over 4.6 mm | 561 mm | 12 | Any material, including 3 mm wood and acrylic |
| 4 × 3.09 in (102 × 78 mm) | Over 6.1 mm | 748 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 4.63 in (152 × 118 mm) | Over 9.1 mm | 1,122 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 6.18 in (203 × 157 mm) | Over 12 mm | 1,496 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 9.26 in (305 × 235 mm) | Over 18 mm | 2,243 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
