Layered water bottle in four colours SVG
Four layers to stack: a pale blue bottle, a darker sleeve round its lower half, a charcoal lid with a carry handle and a flip spout, and a white highlight with one drop.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 40 × 100 mm (1.56 × 3.94 in), scales to any size |
|---|---|
| Pieces | 5 separate pieces |
| Outlines to cut | 5 outlines |
| Cut length | 733 mm at this size |
| Narrowest part | 3.5 mm at this size |
| Nodes | 83 curve and line segments |
| Layers | 4: bottle, sleeve, lid and shine |
Measured from the file. PNG: 837 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.4 × 1 in (10 × 25 mm) | 0.89 mm | 186 mm | 200 | Fine detail: vinyl and paper only, weed with care |
| 0.79 × 2 in (20 × 51 mm) | 1.8 mm | 372 mm | 60 | Vinyl, card and thin sheet |
| 1.18 × 3 in (30 × 76 mm) | 2.7 mm | 559 mm | 24 | Vinyl, card and thin sheet |
| 1.58 × 4 in (40 × 102 mm) | 3.6 mm | 745 mm | 12 | Any material, including 3 mm wood and acrylic |
| 2.37 × 6 in (60 × 152 mm) | 5.3 mm | 1,117 mm | 4 | Any material, including 3 mm wood and acrylic |
| 3.16 × 8 in (80 × 203 mm) | 7.1 mm | 1,489 mm | 3 | Any material, including 3 mm wood and acrylic |
| 4.74 × 12 in (120 × 305 mm) | 11 mm | 2,234 mm | 2 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
