Layered ironworker in eight colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Eight layers to stack: a dark backing a little larger than the drawing, red oxide steel, blue jeans, a grey shirt, a brown harness, bag and boots, the face and hands, a yellow hard hat and a silver wrench.
What is in the file
| Size | 81 × 100 mm (3.2 × 3.94 in), scales to any size |
|---|---|
| Pieces | 15 separate pieces |
| Outlines to cut | 19: 15 outer edges and 4 cut-outs |
| Cut length | 2,003 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 234 curve and line segments |
| Layers | 8: backing, steel, jeans, shirt, harness and boots, skin, hat and wrench |
Measured from the file. PNG: 1,638 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.81 × 1 in (21 × 25 mm) | Over 1.5 mm | 509 mm | 120 | Vinyl, card and thin sheet |
| 1.62 × 2 in (41 × 51 mm) | Over 3 mm | 1,018 mm | 30 | Any material, including 3 mm wood and acrylic |
| 2.44 × 3 in (62 × 76 mm) | Over 4.6 mm | 1,526 mm | 12 | Any material, including 3 mm wood and acrylic |
| 3.25 × 4 in (82 × 102 mm) | Over 6.1 mm | 2,035 mm | 6 | Any material, including 3 mm wood and acrylic |
| 4.87 × 6 in (124 × 152 mm) | Over 9.1 mm | 3,053 mm | 2 | Any material, including 3 mm wood and acrylic |
| 6.5 × 8 in (165 × 203 mm) | Over 12 mm | 4,070 mm | 1 | Any material, including 3 mm wood and acrylic |
| 9.74 × 12 in (247 × 305 mm) | Over 18 mm | 6,105 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
