Layered hammer in three colours SVG
Three layers to stack: a wooden shaft the full length of the hammer, a steel grey head and a dark grip with its four lines cut through to the wood. Drawn upright.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 54 × 100 mm (2.11 × 3.94 in), scales to any size |
|---|---|
| Pieces | 3 separate pieces |
| Outlines to cut | 7: 3 outer edges and 4 cut-outs |
| Cut length | 622 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 74 curve and line segments |
| Layers | 3: wood, steel and grip |
Measured from the file. PNG: 1,108 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.54 × 1 in (14 × 25 mm) | Over 1.5 mm | 158 mm | 160 | Vinyl, card and thin sheet |
| 1.07 × 2 in (27 × 51 mm) | Over 3 mm | 316 mm | 45 | Any material, including 3 mm wood and acrylic |
| 1.61 × 3 in (41 × 76 mm) | Over 4.6 mm | 474 mm | 18 | Any material, including 3 mm wood and acrylic |
| 2.14 × 4 in (54 × 102 mm) | Over 6.1 mm | 632 mm | 10 | Any material, including 3 mm wood and acrylic |
| 3.22 × 6 in (82 × 152 mm) | Over 9.1 mm | 948 mm | 3 | Any material, including 3 mm wood and acrylic |
| 4.29 × 8 in (109 × 203 mm) | Over 12 mm | 1,264 mm | 2 | Any material, including 3 mm wood and acrylic |
| 6.43 × 12 in (163 × 305 mm) | Over 18 mm | 1,896 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
