Layered tape measure tool in three colours SVG
Three layers to stack: a yellow case, a steel grey tape with its marks and hook, and a dark lock button and label. The tape runs out to the left on this one.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 70 mm (3.94 × 2.75 in), scales to any size |
|---|---|
| Pieces | 4 separate pieces |
| Outlines to cut | 5: 4 outer edges and 1 cut-out |
| Cut length | 685 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 77 curve and line segments |
| Layers | 3: case, tape and trim |
Measured from the file. PNG: 2,000 × 1,421 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.7 in (25 × 18 mm) | Over 1.5 mm | 174 mm | 130 | Vinyl, card and thin sheet |
| 2 × 1.4 in (51 × 36 mm) | Over 3 mm | 348 mm | 35 | Any material, including 3 mm wood and acrylic |
| 3 × 2.1 in (76 × 53 mm) | Over 4.6 mm | 522 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.8 in (102 × 71 mm) | Over 6.1 mm | 696 mm | 8 | Any material, including 3 mm wood and acrylic |
| 6 × 4.19 in (152 × 107 mm) | Over 9.1 mm | 1,044 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.59 in (203 × 142 mm) | Over 12 mm | 1,392 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 8.39 in (305 × 213 mm) | Over 18 mm | 2,088 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
