Layered rad tech in seven colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Seven layers to stack: a dark backing a little larger than the figure, teal scrubs, a navy lead apron and collar, the face and hands, dark hair and shoes, a black film, and white for the bones and the belt.
What is in the file
| Size | 68 × 100 mm (2.67 × 3.94 in), scales to any size |
|---|---|
| Pieces | 15 separate pieces |
| Outlines to cut | 16: 15 outer edges and 1 cut-out |
| Cut length | 1,327 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 230 curve and line segments |
| Layers | 7: backing, scrubs, lead apron, skin, hair and shoes, film and bones and belt |
Measured from the file. PNG: 1,381 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.68 × 1 in (17 × 25 mm) | Over 1.5 mm | 337 mm | 130 | Vinyl, card and thin sheet |
| 1.36 × 2 in (34 × 51 mm) | Over 3 mm | 674 mm | 35 | Any material, including 3 mm wood and acrylic |
| 2.03 × 3 in (52 × 76 mm) | Over 4.6 mm | 1,011 mm | 15 | Any material, including 3 mm wood and acrylic |
| 2.71 × 4 in (69 × 102 mm) | Over 6.1 mm | 1,348 mm | 8 | Any material, including 3 mm wood and acrylic |
| 4.07 × 6 in (103 × 152 mm) | Over 9.1 mm | 2,022 mm | 2 | Any material, including 3 mm wood and acrylic |
| 5.42 × 8 in (138 × 203 mm) | Over 12 mm | 2,696 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8.14 × 12 in (207 × 305 mm) | Over 18 mm | 4,045 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
