Layered stone bridge in five colours SVG
Five layers on an arched sky: two green hills, a band of blue water, the grey bridge with its three arches open, and a darker coping with a ring of stones round each arch.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 78 mm (3.94 × 3.06 in), scales to any size |
|---|---|
| Pieces | 8 separate pieces |
| Outlines to cut | 8 outlines |
| Cut length | 1,786 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 120 curve and line segments |
| Layers | 5: sky, hills, water, bridge and coping |
Measured from the file. PNG: 2,000 × 1,571 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.78 in (25 × 20 mm) | Over 1.5 mm | 454 mm | 120 | Vinyl, card and thin sheet |
| 2 × 1.55 in (51 × 39 mm) | Over 3 mm | 907 mm | 30 | Any material, including 3 mm wood and acrylic |
| 3 × 2.33 in (76 × 59 mm) | Over 4.6 mm | 1,361 mm | 12 | Any material, including 3 mm wood and acrylic |
| 4 × 3.11 in (102 × 79 mm) | Over 6.1 mm | 1,815 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 4.66 in (152 × 118 mm) | Over 9.1 mm | 2,722 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 6.22 in (203 × 158 mm) | Over 12 mm | 3,629 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 9.32 in (305 × 237 mm) | Over 18 mm | 5,444 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
