Free anchor SVG

Layered anchor with a rope in two colours SVG

Layered anchor with a rope in two colours, in layered colours — Layered anchor with a rope in two colours. The preview is the SVG file itself.

Two layers: a navy anchor with the path of the rope filled in, and a tan twisted rope to lay on top of it.

Free for personal and commercial use, no sign-up. What you can do with it.

What is in the file

Size	72 × 100 mm (2.84 × 3.94 in), scales to any size
Pieces	2 separate pieces
Outlines to cut	56: 2 outer edges and 54 cut-outs
Cut length	1,463 mm at this size
Narrowest part	5.4 mm at this size
Nodes	345 curve and line segments
Symmetry	Mirror
Layers	2: layer 1 anchor and layer 2 rope

Measured from the file. PNG: 1,463 × 2,000 pixels, transparent. About the three file types.

Will it cut at your size?

Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.

Size, width × height	Narrowest part	Cut length	Fit on a 12 in sheet	Rule of thumb
0.72 × 1 in (18 × 25 mm)	1.4 mm	372 mm	130	Vinyl, card and thin sheet
1.44 × 2 in (37 × 51 mm)	2.7 mm	743 mm	35	Vinyl, card and thin sheet
2.16 × 3 in (55 × 76 mm)	4.1 mm	1,115 mm	15	Any material, including 3 mm wood and acrylic
2.88 × 4 in (73 × 102 mm)	5.5 mm	1,486 mm	6	Any material, including 3 mm wood and acrylic
4.33 × 6 in (110 × 152 mm)	8.2 mm	2,230 mm	2	Any material, including 3 mm wood and acrylic
5.77 × 8 in (147 × 203 mm)	11 mm	2,973 mm	2	Any material, including 3 mm wood and acrylic
8.65 × 12 in (220 × 305 mm)	16 mm	4,459 mm	1	Any material, including 3 mm wood and acrylic

The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
