Layered keyboard in three colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Three layers to stack: a charcoal case with a short lead, pale keys, and seven accent keys in orange red: the corner key, the return key, the space bar and the four keys to its right. Sixty-one keys in all.
What is in the file
| Size | 100 × 47 mm (3.94 × 1.87 in), scales to any size |
|---|---|
| Pieces | 62 separate pieces |
| Outlines to cut | 62 outlines |
| Cut length | 1,493 mm at this size |
| Narrowest part | 3 mm at this size |
| Nodes | 512 curve and line segments |
| Layers | 3: case, keys and accent keys |
Measured from the file. PNG: 2,000 × 988 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.47 in (25 × 12 mm) | 0.76 mm | 379 mm | 180 | Fine detail: vinyl and paper only, weed with care |
| 2 × 0.95 in (51 × 24 mm) | 1.5 mm | 758 mm | 50 | Vinyl, card and thin sheet |
| 3 × 1.42 in (76 × 36 mm) | 2.3 mm | 1,138 mm | 21 | Vinyl, card and thin sheet |
| 4 × 1.9 in (102 × 48 mm) | 3 mm | 1,517 mm | 10 | Any material, including 3 mm wood and acrylic |
| 6 × 2.84 in (152 × 72 mm) | 4.6 mm | 2,275 mm | 4 | Any material, including 3 mm wood and acrylic |
| 8 × 3.79 in (203 × 96 mm) | 6.1 mm | 3,034 mm | 3 | Any material, including 3 mm wood and acrylic |
| 12 × 5.69 in (305 × 144 mm) | 9.1 mm | 4,551 mm | 2 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
