Layered growth chart board with a round top SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
The top of a finished chart in three layers: a board with round shoulders and a hanging hole, the eleven marks from 67 to 77 inches and the numeral 6 beside its foot line. Cut 292.1 mm tall it is true to size, a board 184 mm wide; smaller, it makes a card or a sticker.
What is in the file
| Size | 63 × 100 mm (2.48 × 3.94 in), scales to any size |
|---|---|
| Pieces | 13 separate pieces |
| Outlines to cut | 15: 13 outer edges and 2 cut-outs |
| Cut length | 763 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 95 curve and line segments |
| Layers | 3: board, marks and numeral |
Measured from the file. PNG: 1,288 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.63 × 1 in (16 × 25 mm) | Over 1.5 mm | 194 mm | 140 | Vinyl, card and thin sheet |
| 1.26 × 2 in (32 × 51 mm) | Over 3 mm | 388 mm | 40 | Any material, including 3 mm wood and acrylic |
| 1.89 × 3 in (48 × 76 mm) | Over 4.6 mm | 581 mm | 15 | Any material, including 3 mm wood and acrylic |
| 2.52 × 4 in (64 × 102 mm) | Over 6.1 mm | 775 mm | 8 | Any material, including 3 mm wood and acrylic |
| 3.78 × 6 in (96 × 152 mm) | Over 9.1 mm | 1,163 mm | 3 | Any material, including 3 mm wood and acrylic |
| 5.04 × 8 in (128 × 203 mm) | Over 12 mm | 1,550 mm | 2 | Any material, including 3 mm wood and acrylic |
| 7.56 × 12 in (192 × 305 mm) | Over 18 mm | 2,326 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
