Layered firefighter helmet in three colours SVG
Three layers to stack: a black backing a little bigger than the helmet, the red helmet with its ridges and the border of the plate cut through to the black, and a gold plate on top.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 68 mm (3.94 × 2.66 in), scales to any size |
|---|---|
| Pieces | 3 separate pieces |
| Outlines to cut | 8: 3 outer edges and 5 cut-outs |
| Cut length | 892 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 147 curve and line segments |
| Layers | 3: backing, helmet and plate |
Measured from the file. PNG: 2,000 × 1,377 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.68 in (25 × 17 mm) | Over 1.5 mm | 227 mm | 130 | Vinyl, card and thin sheet |
| 2 × 1.35 in (51 × 34 mm) | Over 3 mm | 453 mm | 35 | Any material, including 3 mm wood and acrylic |
| 3 × 2.03 in (76 × 52 mm) | Over 4.6 mm | 680 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.7 in (102 × 69 mm) | Over 6.1 mm | 906 mm | 8 | Any material, including 3 mm wood and acrylic |
| 6 × 4.06 in (152 × 103 mm) | Over 9.1 mm | 1,359 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.41 in (203 × 137 mm) | Over 12 mm | 1,813 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 8.11 in (305 × 206 mm) | Over 18 mm | 2,719 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
