Layered construction cone in three colours SVG
Three layers to stack: an orange cone, two white reflective bands to lay across it and a charcoal base. Cut the bands from reflective vinyl for a cone that shines under a torch.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 76 × 100 mm (2.98 × 3.94 in), scales to any size |
|---|---|
| Pieces | 4 separate pieces |
| Outlines to cut | 4 outlines |
| Cut length | 670 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 32 curve and line segments |
| Layers | 3: cone, bands and base |
Measured from the file. PNG: 1,533 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.76 × 1 in (19 × 25 mm) | Over 1.5 mm | 170 mm | 120 | Vinyl, card and thin sheet |
| 1.51 × 2 in (38 × 51 mm) | Over 3 mm | 340 mm | 35 | Any material, including 3 mm wood and acrylic |
| 2.27 × 3 in (58 × 76 mm) | Over 4.6 mm | 511 mm | 12 | Any material, including 3 mm wood and acrylic |
| 3.03 × 4 in (77 × 102 mm) | Over 6.1 mm | 681 mm | 6 | Any material, including 3 mm wood and acrylic |
| 4.54 × 6 in (115 × 152 mm) | Over 9.1 mm | 1,021 mm | 2 | Any material, including 3 mm wood and acrylic |
| 6.06 × 8 in (154 × 203 mm) | Over 12 mm | 1,361 mm | 1 | Any material, including 3 mm wood and acrylic |
| 9.08 × 12 in (231 × 305 mm) | Over 18 mm | 2,042 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
