Layered traffic light signal in five colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers to stack: a grey pole and foot, a charcoal case with its six hoods, and a red, an amber and a green lamp. Glue the lamps on top of the case in that order.
What is in the file
| Size | 42 × 100 mm (1.67 × 3.94 in), scales to any size |
|---|---|
| Pieces | 5 separate pieces |
| Outlines to cut | 5 outlines |
| Cut length | 476 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 68 curve and line segments |
| Layers | 5: pole, case, red, amber and green |
Measured from the file. PNG: 890 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.42 × 1 in (11 × 25 mm) | Over 1.5 mm | 121 mm | 190 | Vinyl, card and thin sheet |
| 0.85 × 2 in (21 × 51 mm) | Over 3 mm | 242 mm | 55 | Any material, including 3 mm wood and acrylic |
| 1.27 × 3 in (32 × 76 mm) | Over 4.6 mm | 363 mm | 24 | Any material, including 3 mm wood and acrylic |
| 1.69 × 4 in (43 × 102 mm) | Over 6.1 mm | 484 mm | 12 | Any material, including 3 mm wood and acrylic |
| 2.54 × 6 in (64 × 152 mm) | Over 9.1 mm | 725 mm | 4 | Any material, including 3 mm wood and acrylic |
| 3.38 × 8 in (86 × 203 mm) | Over 12 mm | 967 mm | 3 | Any material, including 3 mm wood and acrylic |
| 5.08 × 12 in (129 × 305 mm) | Over 18 mm | 1,451 mm | 2 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
