Layered wooden ruler in three colours SVG
Three layers to stack: a yellow wooden ruler, dark marks to lay along its edge and a silver cap for each end. It slopes the other way from the plain ruler.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 72 mm (3.94 × 2.81 in), scales to any size |
|---|---|
| Pieces | 20 separate pieces |
| Outlines to cut | 21: 20 outer edges and 1 cut-out |
| Cut length | 611 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 92 curve and line segments |
| Layers | 3: wood, marks and caps |
Measured from the file. PNG: 2,000 × 1,452 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.72 in (25 × 18 mm) | Over 1.5 mm | 155 mm | 130 | Vinyl, card and thin sheet |
| 2 × 1.43 in (51 × 36 mm) | Over 3 mm | 310 mm | 35 | Any material, including 3 mm wood and acrylic |
| 3 × 2.14 in (76 × 54 mm) | Over 4.6 mm | 466 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.86 in (102 × 73 mm) | Over 6.1 mm | 621 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 4.29 in (152 × 109 mm) | Over 9.1 mm | 931 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.72 in (203 × 145 mm) | Over 12 mm | 1,242 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 8.58 in (305 × 218 mm) | Over 18 mm | 1,862 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
