Layered lineman in seven colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Seven layers to stack: a dark backing a little larger than the whole drawing, a brown pole, pale blue insulators, navy trousers, an orange shirt, brown belt and boots, and a cream hat, face and hands.
What is in the file
| Size | 65 × 100 mm (2.57 × 3.94 in), scales to any size |
|---|---|
| Pieces | 18 separate pieces |
| Outlines to cut | 25: 18 outer edges and 7 cut-outs |
| Cut length | 1,607 mm at this size |
| Narrowest part | 4 mm at this size |
| Nodes | 383 curve and line segments |
| Layers | 7: backing, pole, insulators, trousers, shirt, gear and hat and skin |
Measured from the file. PNG: 1,331 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.65 × 1 in (17 × 25 mm) | 1 mm | 408 mm | 140 | Vinyl, card and thin sheet |
| 1.3 × 2 in (33 × 51 mm) | 2 mm | 816 mm | 40 | Vinyl, card and thin sheet |
| 1.96 × 3 in (50 × 76 mm) | 3 mm | 1,225 mm | 15 | Any material, including 3 mm wood and acrylic |
| 2.61 × 4 in (66 × 102 mm) | 4.1 mm | 1,633 mm | 8 | Any material, including 3 mm wood and acrylic |
| 3.91 × 6 in (99 × 152 mm) | 6.1 mm | 2,449 mm | 2 | Any material, including 3 mm wood and acrylic |
| 5.22 × 8 in (132 × 203 mm) | 8.1 mm | 3,265 mm | 2 | Any material, including 3 mm wood and acrylic |
| 7.82 × 12 in (199 × 305 mm) | 12 mm | 4,898 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
