Layered game controller in four colours SVG
Four layers to stack: a charcoal pad, pale grey shoulders, cross pad and pills, red buttons and black thumbsticks. Nothing needs a bridge, because every ring is its own piece.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 82 mm (3.94 × 3.24 in), scales to any size |
|---|---|
| Pieces | 14 separate pieces |
| Outlines to cut | 16: 14 outer edges and 2 cut-outs |
| Cut length | 789 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 136 curve and line segments |
| Layers | 4: pad, grey, buttons and sticks |
Measured from the file. PNG: 2,000 × 1,662 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.82 in (25 × 21 mm) | Over 1.5 mm | 200 mm | 110 | Vinyl, card and thin sheet |
| 2 × 1.65 in (51 × 42 mm) | Over 3 mm | 401 mm | 30 | Any material, including 3 mm wood and acrylic |
| 3 × 2.47 in (76 × 63 mm) | Over 4.6 mm | 601 mm | 12 | Any material, including 3 mm wood and acrylic |
| 4 × 3.3 in (102 × 84 mm) | Over 6.1 mm | 802 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 4.94 in (152 × 126 mm) | Over 9.1 mm | 1,202 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 6.59 in (203 × 167 mm) | Over 12 mm | 1,603 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 9.89 in (305 × 251 mm) | Over 18 mm | 2,405 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
