Layered raglan T-shirt in two colours SVG
Two layers: a pale shirt with three-quarter sleeves, and the sleeves and neck band in a second colour to lay on top. The colours of a baseball shirt, ready to swap.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 92 mm (3.94 × 3.61 in), scales to any size |
|---|---|
| Pieces | 4 separate pieces |
| Outlines to cut | 4 outlines |
| Cut length | 728 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 94 curve and line segments |
| Symmetry | Mirror |
| Layers | 2: body and sleeves |
Measured from the file. PNG: 2,000 × 1,838 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.92 in (25 × 23 mm) | Over 1.5 mm | 185 mm | 100 | Vinyl, card and thin sheet |
| 2 × 1.83 in (51 × 47 mm) | Over 3 mm | 370 mm | 30 | Any material, including 3 mm wood and acrylic |
| 3 × 2.75 in (76 × 70 mm) | Over 4.6 mm | 555 mm | 12 | Any material, including 3 mm wood and acrylic |
| 4 × 3.66 in (102 × 93 mm) | Over 6.1 mm | 740 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 5.5 in (152 × 140 mm) | Over 9.1 mm | 1,109 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 7.33 in (203 × 186 mm) | Over 12 mm | 1,479 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 10.99 in (305 × 279 mm) | Over 18 mm | 2,219 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
