Kettle grill in two colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
A dark layer with the stand, the rim, the grips and an edge all round, a red layer for the bowl and lid with the seam and the vent cut out, and three grey puffs of smoke rising from the vent. Stack the red on the dark.
What is in the file
| Size | 62 × 100 mm (2.45 × 3.94 in), scales to any size |
|---|---|
| Pieces | 5 separate pieces |
| Outlines to cut | 9: 5 outer edges and 4 cut-outs |
| Cut length | 819 mm at this size |
| Narrowest part | 2.2 mm at this size |
| Nodes | 81 curve and line segments |
| Layers | 3: stand and trim, kettle and smoke |
Measured from the file. PNG: 1,275 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.62 × 1 in (16 × 25 mm) | 0.56 mm | 208 mm | 140 | Fine detail: vinyl and paper only, weed with care |
| 1.25 × 2 in (32 × 51 mm) | 1.1 mm | 416 mm | 40 | Vinyl, card and thin sheet |
| 1.87 × 3 in (47 × 76 mm) | 1.7 mm | 624 mm | 15 | Vinyl, card and thin sheet |
| 2.49 × 4 in (63 × 102 mm) | 2.2 mm | 832 mm | 8 | Vinyl, card and thin sheet |
| 3.74 × 6 in (95 × 152 mm) | 3.4 mm | 1,248 mm | 3 | Any material, including 3 mm wood and acrylic |
| 4.98 × 8 in (127 × 203 mm) | 4.5 mm | 1,664 mm | 2 | Any material, including 3 mm wood and acrylic |
| 7.48 × 12 in (190 × 305 mm) | 6.7 mm | 2,496 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
