Exploding box with three layers SVG
Three crosses, each 2 mm smaller than the last, to cut in three colours and glue middle to middle. Cut 165 mm across, the outer walls are 55 mm square. The lid of the plain explosion box, cut 265 mm wide, fits it.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 100 mm (3.94 × 3.94 in), scales to any size |
|---|---|
| Pieces | 3 separate pieces |
| Outlines to cut | 71: 3 outer edges and 68 cut-outs |
| Cut length | 1,530 mm at this size |
| Narrowest part | 2.4 mm at this size |
| Nodes | 308 curve and line segments |
| Layers | 3: outer walls, middle walls and inner walls |
Measured from the file. PNG: 2,000 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 1 in (25 × 25 mm) | 0.61 mm | 389 mm | 100 | Fine detail: vinyl and paper only, weed with care |
| 2 × 2 in (51 × 51 mm) | 1.2 mm | 777 mm | 25 | Vinyl, card and thin sheet |
| 3 × 3 in (76 × 76 mm) | 1.8 mm | 1,166 mm | 9 | Vinyl, card and thin sheet |
| 4 × 4 in (102 × 102 mm) | 2.4 mm | 1,554 mm | 4 | Vinyl, card and thin sheet |
| 6 × 6 in (152 × 152 mm) | 3.7 mm | 2,332 mm | 1 | Any material, including 3 mm wood and acrylic |
| 8 × 8 in (203 × 203 mm) | 4.9 mm | 3,109 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 12 in (305 × 305 mm) | 7.3 mm | 4,663 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
