Layered excavator in four colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers in four colours to stack: a charcoal backing, a yellow house, cab and arm, blue glass, charcoal tracks, bucket and vents, and silver hydraulic rams on top.
What is in the file
| Size | 100 × 72 mm (3.94 × 2.85 in), scales to any size |
|---|---|
| Pieces | 13 separate pieces |
| Outlines to cut | 20: 13 outer edges and 7 cut-outs |
| Cut length | 1,556 mm at this size |
| Narrowest part | 5.3 mm at this size |
| Nodes | 222 curve and line segments |
| Layers | 5: backing, body and arm, glass, tracks and bucket and rams |
Measured from the file. PNG: 2,000 × 1,469 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.72 in (25 × 18 mm) | 1.3 mm | 395 mm | 130 | Vinyl, card and thin sheet |
| 2 × 1.45 in (51 × 37 mm) | 2.7 mm | 790 mm | 35 | Vinyl, card and thin sheet |
| 3 × 2.17 in (76 × 55 mm) | 4 mm | 1,186 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.9 in (102 × 74 mm) | 5.4 mm | 1,581 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 4.34 in (152 × 110 mm) | 8.1 mm | 2,371 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.79 in (203 × 147 mm) | 11 mm | 3,162 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 8.69 in (305 × 221 mm) | 16 mm | 4,743 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
