Oblong box template with coloured panels SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
An oblong box and lid, with a panel for the top of the lid and one for each long wall to cut in a second colour. Cut 260 mm wide, the box is 81 by 51 mm and 30 mm deep. Each panel is 3 mm smaller than its face all round.
What is in the file
| Size | 100 × 43 mm (3.94 × 1.69 in), scales to any size |
|---|---|
| Pieces | 5 separate pieces |
| Outlines to cut | 56: 5 outer edges and 51 cut-outs |
| Cut length | 972 mm at this size |
| Narrowest part | 0.8 mm at this size |
| Nodes | 282 curve and line segments |
| Layers | 2: box and lid and panels |
Measured from the file. PNG: 2,000 × 900 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.43 in (25 × 11 mm) | 0.2 mm | 247 mm | 190 | Too fine for most machines |
| 2 × 0.86 in (51 × 22 mm) | 0.41 mm | 494 mm | 55 | Too fine for most machines |
| 3 × 1.28 in (76 × 33 mm) | 0.61 mm | 741 mm | 24 | Fine detail: vinyl and paper only, weed with care |
| 4 × 1.71 in (102 × 43 mm) | 0.81 mm | 988 mm | 12 | Fine detail: vinyl and paper only, weed with care |
| 6 × 2.57 in (152 × 65 mm) | 1.2 mm | 1,481 mm | 4 | Vinyl, card and thin sheet |
| 8 × 3.42 in (203 × 87 mm) | 1.6 mm | 1,975 mm | 3 | Vinyl, card and thin sheet |
| 12 × 5.14 in (305 × 130 mm) | 2.4 mm | 2,963 mm | 2 | Vinyl, card and thin sheet |
The narrowest part is the thinnest neck or wall beside a cut-out; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
