Layered ATV in four colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers in four colours to stack: a charcoal backing, red bodywork, a charcoal seat with the handlebars and tyres, silver racks, bumper and wheel centres, and a grey engine block.
What is in the file
| Size | 100 × 65 mm (3.94 × 2.56 in), scales to any size |
|---|---|
| Pieces | 11 separate pieces |
| Outlines to cut | 24: 11 outer edges and 13 cut-outs |
| Cut length | 1,638 mm at this size |
| Narrowest part | 5 mm at this size |
| Nodes | 434 curve and line segments |
| Layers | 5: backing, bodywork, seat and tyres, racks and wheels and engine |
Measured from the file. PNG: 2,000 × 1,329 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.65 in (25 × 17 mm) | 1.3 mm | 416 mm | 140 | Vinyl, card and thin sheet |
| 2 × 1.3 in (51 × 33 mm) | 2.5 mm | 832 mm | 40 | Vinyl, card and thin sheet |
| 3 × 1.95 in (76 × 50 mm) | 3.8 mm | 1,248 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.6 in (102 × 66 mm) | 5.1 mm | 1,664 mm | 8 | Any material, including 3 mm wood and acrylic |
| 6 × 3.91 in (152 × 99 mm) | 7.6 mm | 2,496 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.21 in (203 × 132 mm) | 10 mm | 3,328 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 7.81 in (305 × 198 mm) | 15 mm | 4,993 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
