Layered covered wagon in five colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers to stack: the whole wagon and its strip of ground in dark brown, a cream canvas bonnet, tan hoop lines, a chestnut box and seat, and a green band of grass along the ground.
What is in the file
| Size | 100 × 81 mm (3.94 × 3.17 in), scales to any size |
|---|---|
| Pieces | 8 separate pieces |
| Outlines to cut | 34: 8 outer edges and 26 cut-outs |
| Cut length | 1,719 mm at this size |
| Narrowest part | 2.4 mm at this size |
| Nodes | 267 curve and line segments |
| Layers | 5: wagon, canvas, hoops, box and grass |
Measured from the file. PNG: 2,000 × 1,627 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.81 in (25 × 20 mm) | 0.61 mm | 437 mm | 120 | Fine detail: vinyl and paper only, weed with care |
| 2 × 1.61 in (51 × 41 mm) | 1.2 mm | 873 mm | 30 | Vinyl, card and thin sheet |
| 3 × 2.42 in (76 × 61 mm) | 1.8 mm | 1,310 mm | 12 | Vinyl, card and thin sheet |
| 4 × 3.22 in (102 × 82 mm) | 2.4 mm | 1,747 mm | 6 | Vinyl, card and thin sheet |
| 6 × 4.84 in (152 × 123 mm) | 3.7 mm | 2,620 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 6.45 in (203 × 164 mm) | 4.9 mm | 3,493 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 9.67 in (305 × 246 mm) | 7.3 mm | 5,240 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
