Layered Viking ship in five colours SVG
The same ship in layers: a blue sea, a brown hull with mast, oars and rigging, a cream sail, four red stripes and six gold shields. Stack them in that order.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 90 mm (3.94 × 3.53 in), scales to any size |
|---|---|
| Pieces | 13 separate pieces |
| Outlines to cut | 20: 13 outer edges and 7 cut-outs |
| Cut length | 1,864 mm at this size |
| Narrowest part | 5.3 mm at this size |
| Nodes | 249 curve and line segments |
| Layers | 5: layer 1 sea, layer 2 ship, layer 3 sail, layer 4 stripes and layer 5 shields |
Measured from the file. PNG: 2,000 × 1,802 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.9 in (25 × 23 mm) | 1.3 mm | 473 mm | 110 | Vinyl, card and thin sheet |
| 2 × 1.79 in (51 × 46 mm) | 2.7 mm | 947 mm | 30 | Vinyl, card and thin sheet |
| 3 × 2.69 in (76 × 68 mm) | 4 mm | 1,420 mm | 12 | Any material, including 3 mm wood and acrylic |
| 4 × 3.59 in (102 × 91 mm) | 5.4 mm | 1,894 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 5.38 in (152 × 137 mm) | 8.1 mm | 2,841 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 7.18 in (203 × 182 mm) | 11 mm | 3,788 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 10.76 in (305 × 273 mm) | 16 mm | 5,681 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
