Layered submarine in five colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers to stack: a dark backing, an orange hull, teal fins, hatch, periscope and propeller, yellow porthole rims with a band round the nose, and pale blue glass.
What is in the file
| Size | 100 × 67 mm (3.94 × 2.62 in), scales to any size |
|---|---|
| Pieces | 13 separate pieces |
| Outlines to cut | 15: 13 outer edges and 2 cut-outs |
| Cut length | 1,168 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 151 curve and line segments |
| Layers | 5: backing, hull, trim, rims and glass |
Measured from the file. PNG: 2,000 × 1,358 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.67 in (25 × 17 mm) | Over 1.5 mm | 297 mm | 140 | Vinyl, card and thin sheet |
| 2 × 1.33 in (51 × 34 mm) | Over 3 mm | 593 mm | 35 | Any material, including 3 mm wood and acrylic |
| 3 × 2 in (76 × 51 mm) | Over 4.6 mm | 890 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.66 in (102 × 68 mm) | Over 6.1 mm | 1,187 mm | 8 | Any material, including 3 mm wood and acrylic |
| 6 × 4 in (152 × 101 mm) | Over 9.1 mm | 1,780 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.33 in (203 × 135 mm) | Over 12 mm | 2,373 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 7.99 in (305 × 203 mm) | Over 18 mm | 3,560 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
