Layered sonographer in six colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Six layers to stack: a dark backing a little larger than the figure, purple scrubs, the face and hands, dark hair, a grey probe and cable, and white for the gel bottle and the shoes.
What is in the file
| Size | 68 × 100 mm (2.67 × 3.94 in), scales to any size |
|---|---|
| Pieces | 10 separate pieces |
| Outlines to cut | 13: 10 outer edges and 3 cut-outs |
| Cut length | 1,521 mm at this size |
| Narrowest part | 5.4 mm at this size |
| Nodes | 288 curve and line segments |
| Layers | 6: backing, scrubs, skin, hair, probe and cable and gel and shoes |
Measured from the file. PNG: 1,383 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.68 × 1 in (17 × 25 mm) | 1.4 mm | 386 mm | 130 | Vinyl, card and thin sheet |
| 1.36 × 2 in (34 × 51 mm) | 2.7 mm | 773 mm | 35 | Vinyl, card and thin sheet |
| 2.04 × 3 in (52 × 76 mm) | 4.1 mm | 1,159 mm | 15 | Any material, including 3 mm wood and acrylic |
| 2.72 × 4 in (69 × 102 mm) | 5.5 mm | 1,545 mm | 8 | Any material, including 3 mm wood and acrylic |
| 4.07 × 6 in (103 × 152 mm) | 8.2 mm | 2,318 mm | 2 | Any material, including 3 mm wood and acrylic |
| 5.43 × 8 in (138 × 203 mm) | 11 mm | 3,091 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8.15 × 12 in (207 × 305 mm) | 16 mm | 4,636 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
