Layered semi truck big rig in five colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Six layers in five colours to stack: a charcoal backing, a silver trailer, a red tractor with a matching stripe along the trailer, blue glass, charcoal tyres, and chrome hubs and stack.
What is in the file
| Size | 100 × 42 mm (3.94 × 1.67 in), scales to any size |
|---|---|
| Pieces | 20 separate pieces |
| Outlines to cut | 20 outlines |
| Cut length | 1,216 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 197 curve and line segments |
| Layers | 6: backing, trailer, tractor, glass, tyres and chrome |
Measured from the file. PNG: 2,000 × 890 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.42 in (25 × 11 mm) | Over 1.5 mm | 309 mm | 190 | Vinyl, card and thin sheet |
| 2 × 0.85 in (51 × 21 mm) | Over 3 mm | 618 mm | 55 | Any material, including 3 mm wood and acrylic |
| 3 × 1.27 in (76 × 32 mm) | Over 4.6 mm | 927 mm | 24 | Any material, including 3 mm wood and acrylic |
| 4 × 1.69 in (102 × 43 mm) | Over 6.1 mm | 1,235 mm | 12 | Any material, including 3 mm wood and acrylic |
| 6 × 2.54 in (152 × 64 mm) | Over 9.1 mm | 1,853 mm | 4 | Any material, including 3 mm wood and acrylic |
| 8 × 3.38 in (203 × 86 mm) | Over 12 mm | 2,471 mm | 3 | Any material, including 3 mm wood and acrylic |
| 12 × 5.08 in (305 × 129 mm) | Over 18 mm | 3,706 mm | 2 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
