Layered phlebotomy tubes in seven colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Three tubes side by side in seven layers: a dark backing, pale glass, dark red blood, white labels, and a lavender, a red and a light blue stopper, the three colours seen most often.
What is in the file
| Size | 78 × 100 mm (3.06 × 3.94 in), scales to any size |
|---|---|
| Pieces | 15 separate pieces |
| Outlines to cut | 18: 15 outer edges and 3 cut-outs |
| Cut length | 2,407 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 178 curve and line segments |
| Layers | 7: backing, glass, blood, labels, lavender stopper, red stopper and blue stopper |
Measured from the file. PNG: 1,573 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.78 × 1 in (20 × 25 mm) | Over 1.5 mm | 611 mm | 120 | Vinyl, card and thin sheet |
| 1.56 × 2 in (40 × 51 mm) | Over 3 mm | 1,223 mm | 30 | Any material, including 3 mm wood and acrylic |
| 2.33 × 3 in (59 × 76 mm) | Over 4.6 mm | 1,834 mm | 12 | Any material, including 3 mm wood and acrylic |
| 3.11 × 4 in (79 × 102 mm) | Over 6.1 mm | 2,446 mm | 6 | Any material, including 3 mm wood and acrylic |
| 4.67 × 6 in (119 × 152 mm) | Over 9.1 mm | 3,668 mm | 2 | Any material, including 3 mm wood and acrylic |
| 6.22 × 8 in (158 × 203 mm) | Over 12 mm | 4,891 mm | 1 | Any material, including 3 mm wood and acrylic |
| 9.34 × 12 in (237 × 305 mm) | Over 18 mm | 7,337 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
More phlebotomy SVG files
-
Phlebotomy blood tube with drops Solid · 3 pieces -
Phlebotomy butterfly needle Solid · one piece -
Phlebotomy needle and tube holder Solid · one piece -
Phlebotomy needle decal with a heart of tubing Solid · one piece -
Phlebotomy heartbeat line with a tube and a drop Solid · one piece -
Phlebotomist holding up a tube Solid · one piece -
Phlebotomy silhouette with a trolley Solid · one piece -
Phlebotomy tube rack with four tubes Solid · one piece
