Layered light bulb in four colours SVG
Four layers to stack: a warm yellow bulb, a grey screw base, an orange filament and a pale highlight on the glass.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 65 × 100 mm (2.54 × 3.94 in), scales to any size |
|---|---|
| Pieces | 4 separate pieces |
| Outlines to cut | 8: 4 outer edges and 4 cut-outs |
| Cut length | 814 mm at this size |
| Narrowest part | 2.4 mm at this size |
| Nodes | 138 curve and line segments |
| Layers | 4: glass, base, filament and shine |
Measured from the file. PNG: 1,317 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.65 × 1 in (16 × 25 mm) | 0.61 mm | 207 mm | 140 | Fine detail: vinyl and paper only, weed with care |
| 1.29 × 2 in (33 × 51 mm) | 1.2 mm | 414 mm | 40 | Vinyl, card and thin sheet |
| 1.93 × 3 in (49 × 76 mm) | 1.8 mm | 620 mm | 15 | Vinyl, card and thin sheet |
| 2.58 × 4 in (66 × 102 mm) | 2.4 mm | 827 mm | 8 | Vinyl, card and thin sheet |
| 3.87 × 6 in (98 × 152 mm) | 3.7 mm | 1,241 mm | 2 | Any material, including 3 mm wood and acrylic |
| 5.16 × 8 in (131 × 203 mm) | 4.9 mm | 1,654 mm | 2 | Any material, including 3 mm wood and acrylic |
| 7.74 × 12 in (197 × 305 mm) | 7.3 mm | 2,481 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
