Layered helicopter in four colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers in four colours to stack: a charcoal backing, a red cabin and tail, a white stripe along the side, blue glass, and the rotors, engine housing and skids in charcoal on top.
What is in the file
| Size | 100 × 48 mm (3.94 × 1.88 in), scales to any size |
|---|---|
| Pieces | 12 separate pieces |
| Outlines to cut | 13: 12 outer edges and 1 cut-out |
| Cut length | 1,343 mm at this size |
| Narrowest part | 4.8 mm at this size |
| Nodes | 175 curve and line segments |
| Layers | 5: backing, body, stripe, glass and rotor and skids |
Measured from the file. PNG: 2,000 × 996 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.48 in (25 × 12 mm) | 1.2 mm | 341 mm | 180 | Vinyl, card and thin sheet |
| 2 × 0.96 in (51 × 24 mm) | 2.4 mm | 682 mm | 50 | Vinyl, card and thin sheet |
| 3 × 1.43 in (76 × 36 mm) | 3.7 mm | 1,023 mm | 21 | Any material, including 3 mm wood and acrylic |
| 4 × 1.91 in (102 × 49 mm) | 4.9 mm | 1,364 mm | 10 | Any material, including 3 mm wood and acrylic |
| 6 × 2.87 in (152 × 73 mm) | 7.3 mm | 2,047 mm | 3 | Any material, including 3 mm wood and acrylic |
| 8 × 3.82 in (203 × 97 mm) | 9.8 mm | 2,729 mm | 3 | Any material, including 3 mm wood and acrylic |
| 12 × 5.74 in (305 × 146 mm) | 15 mm | 4,093 mm | 2 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
