Layered garbage truck in six colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Seven layers in six colours to stack: a charcoal backing, a green body, a white cab, blue glass, dark green ribs and hopper mouth, charcoal tyres, and amber hubs and beacon.
What is in the file
| Size | 100 × 49 mm (3.94 × 1.93 in), scales to any size |
|---|---|
| Pieces | 19 separate pieces |
| Outlines to cut | 20: 19 outer edges and 1 cut-out |
| Cut length | 1,158 mm at this size |
| Narrowest part | 4.5 mm at this size |
| Nodes | 190 curve and line segments |
| Layers | 7: backing, body, cab, glass, ribs and hopper, tyres and hubs and lamp |
Measured from the file. PNG: 2,000 × 1,021 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.49 in (25 × 12 mm) | 1.1 mm | 294 mm | 170 | Vinyl, card and thin sheet |
| 2 × 0.98 in (51 × 25 mm) | 2.3 mm | 588 mm | 50 | Vinyl, card and thin sheet |
| 3 × 1.47 in (76 × 37 mm) | 3.4 mm | 882 mm | 21 | Any material, including 3 mm wood and acrylic |
| 4 × 1.96 in (102 × 50 mm) | 4.6 mm | 1,177 mm | 10 | Any material, including 3 mm wood and acrylic |
| 6 × 2.95 in (152 × 75 mm) | 6.9 mm | 1,765 mm | 3 | Any material, including 3 mm wood and acrylic |
| 8 × 3.93 in (203 × 100 mm) | 9.1 mm | 2,353 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 5.89 in (305 × 150 mm) | 14 mm | 3,530 mm | 2 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
