Layered EMT ambulance in six colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Seven layers in six colours to stack: a charcoal backing, a white body, an orange stripe and star, pale blue glass, red lights, charcoal tyres and silver hubs.
What is in the file
| Size | 100 × 66 mm (3.94 × 2.61 in), scales to any size |
|---|---|
| Pieces | 13 separate pieces |
| Outlines to cut | 15: 13 outer edges and 2 cut-outs |
| Cut length | 1,236 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 178 curve and line segments |
| Layers | 7: backing, body, stripe, glass, lights, tyres and hubs |
Measured from the file. PNG: 2,000 × 1,350 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.66 in (25 × 17 mm) | Over 1.5 mm | 314 mm | 140 | Vinyl, card and thin sheet |
| 2 × 1.32 in (51 × 34 mm) | Over 3 mm | 628 mm | 40 | Any material, including 3 mm wood and acrylic |
| 3 × 1.99 in (76 × 50 mm) | Over 4.6 mm | 942 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.65 in (102 × 67 mm) | Over 6.1 mm | 1,256 mm | 8 | Any material, including 3 mm wood and acrylic |
| 6 × 3.97 in (152 × 101 mm) | Over 9.1 mm | 1,884 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.3 in (203 × 135 mm) | Over 12 mm | 2,512 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 7.94 in (305 × 202 mm) | Over 18 mm | 3,767 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
