Dog tags in three colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
The pair of tags as three layers: black rubber silencers a little larger than the tags, the two silver tags, and a grey ball chain. Stack the tags on the silencers and the chain on top.
What is in the file
| Size | 55 × 100 mm (2.16 × 3.94 in), scales to any size |
|---|---|
| Pieces | 3 separate pieces |
| Outlines to cut | 12: 3 outer edges and 9 cut-outs |
| Cut length | 1,117 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 226 curve and line segments |
| Layers | 3: silencers, tags and chain |
Measured from the file. PNG: 1,133 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.55 × 1 in (14 × 25 mm) | Over 1.5 mm | 284 mm | 160 | Vinyl, card and thin sheet |
| 1.1 × 2 in (28 × 51 mm) | Over 3 mm | 567 mm | 45 | Any material, including 3 mm wood and acrylic |
| 1.65 × 3 in (42 × 76 mm) | Over 4.6 mm | 851 mm | 18 | Any material, including 3 mm wood and acrylic |
| 2.2 × 4 in (56 × 102 mm) | Over 6.1 mm | 1,135 mm | 10 | Any material, including 3 mm wood and acrylic |
| 3.29 × 6 in (84 × 152 mm) | Over 9.1 mm | 1,702 mm | 3 | Any material, including 3 mm wood and acrylic |
| 4.39 × 8 in (112 × 203 mm) | Over 12 mm | 2,270 mm | 2 | Any material, including 3 mm wood and acrylic |
| 6.59 × 12 in (167 × 305 mm) | Over 18 mm | 3,405 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
