Layered dispatcher thin gold line heart SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Three layers to stack: a black heart, a single gold line across it, and a white telephone handset laid over the top. The gold line is about 8 mm deep at 100 mm wide.
What is in the file
| Size | 100 × 90 mm (3.94 × 3.56 in), scales to any size |
|---|---|
| Pieces | 3 separate pieces |
| Outlines to cut | 3 outlines |
| Cut length | 623 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 46 curve and line segments |
| Layers | 3: black heart, gold line and white handset |
Measured from the file. PNG: 2,000 × 1,815 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.9 in (25 × 23 mm) | Over 1.5 mm | 158 mm | 110 | Vinyl, card and thin sheet |
| 2 × 1.81 in (51 × 46 mm) | Over 3 mm | 316 mm | 30 | Any material, including 3 mm wood and acrylic |
| 3 × 2.71 in (76 × 69 mm) | Over 4.6 mm | 475 mm | 12 | Any material, including 3 mm wood and acrylic |
| 4 × 3.62 in (102 × 92 mm) | Over 6.1 mm | 633 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 5.42 in (152 × 138 mm) | Over 9.1 mm | 949 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 7.23 in (203 × 184 mm) | Over 12 mm | 1,266 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 10.85 in (305 × 276 mm) | Over 18 mm | 1,899 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
