Layered crayon in three colours SVG
Three layers to stack: a red wax crayon, a paler paper wrapper and dark bands with an oval for a name. Drawn lying level, and easy to recolour for a whole box.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 20 mm (3.94 × 0.79 in), scales to any size |
|---|---|
| Pieces | 5 separate pieces |
| Outlines to cut | 6: 5 outer edges and 1 cut-out |
| Cut length | 630 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 56 curve and line segments |
| Layers | 3: wax, wrapper and bands |
Measured from the file. PNG: 2,000 × 462 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.2 in (25 × 5 mm) | Over 1.5 mm | 160 mm | 300 | Vinyl, card and thin sheet |
| 2 × 0.4 in (51 × 10 mm) | Over 3 mm | 320 mm | 100 | Any material, including 3 mm wood and acrylic |
| 3 × 0.6 in (76 × 15 mm) | Over 4.6 mm | 480 mm | 45 | Any material, including 3 mm wood and acrylic |
| 4 × 0.8 in (102 × 20 mm) | Over 6.1 mm | 640 mm | 24 | Any material, including 3 mm wood and acrylic |
| 6 × 1.2 in (152 × 30 mm) | Over 9.1 mm | 960 mm | 8 | Any material, including 3 mm wood and acrylic |
| 8 × 1.6 in (203 × 41 mm) | Over 12 mm | 1,280 mm | 6 | Any material, including 3 mm wood and acrylic |
| 12 × 2.4 in (305 × 61 mm) | Over 18 mm | 1,920 mm | 4 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
