Layered retro computer in five colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers to stack: a beige case with its keyboard and lead, a dark screen, five green lines of code as plain bars, brown slots and vents, and pale keys. Cut each from its own sheet and build up from the case.
What is in the file
| Size | 100 × 96 mm (3.94 × 3.77 in), scales to any size |
|---|---|
| Pieces | 48 separate pieces |
| Outlines to cut | 48 outlines |
| Cut length | 1,753 mm at this size |
| Narrowest part | 1.6 mm at this size |
| Nodes | 310 curve and line segments |
| Layers | 5: case, screen, code, slots and vents and keys |
Measured from the file. PNG: 2,000 × 1,919 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.96 in (25 × 24 mm) | 0.41 mm | 445 mm | 100 | Too fine for most machines |
| 2 × 1.92 in (51 × 49 mm) | 0.81 mm | 891 mm | 25 | Fine detail: vinyl and paper only, weed with care |
| 3 × 2.87 in (76 × 73 mm) | 1.2 mm | 1,336 mm | 9 | Vinyl, card and thin sheet |
| 4 × 3.83 in (102 × 97 mm) | 1.6 mm | 1,781 mm | 6 | Vinyl, card and thin sheet |
| 6 × 5.75 in (152 × 146 mm) | 2.4 mm | 2,672 mm | 2 | Vinyl, card and thin sheet |
| 8 × 7.66 in (203 × 195 mm) | 3.3 mm | 3,562 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 11.5 in (305 × 292 mm) | 4.9 mm | 5,343 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
