Layered color guard flag in three colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Three layers to stack: a silk in a deep colour, a silver pole with its two tips cut in one piece, and a band and a star in a bright colour. The flag leans the other way from the single-colour one. Change the silk colours to your own.
What is in the file
| Size | 87 × 100 mm (3.42 × 3.94 in), scales to any size |
|---|---|
| Pieces | 4 separate pieces |
| Outlines to cut | 4 outlines |
| Cut length | 538 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 76 curve and line segments |
| Layers | 3: silk, pole and tips and band and star |
Measured from the file. PNG: 1,746 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.87 × 1 in (22 × 25 mm) | Over 1.5 mm | 137 mm | 110 | Vinyl, card and thin sheet |
| 1.74 × 2 in (44 × 51 mm) | Over 3 mm | 273 mm | 30 | Any material, including 3 mm wood and acrylic |
| 2.6 × 3 in (66 × 76 mm) | Over 4.6 mm | 410 mm | 12 | Any material, including 3 mm wood and acrylic |
| 3.47 × 4 in (88 × 102 mm) | Over 6.1 mm | 547 mm | 6 | Any material, including 3 mm wood and acrylic |
| 5.21 × 6 in (132 × 152 mm) | Over 9.1 mm | 820 mm | 2 | Any material, including 3 mm wood and acrylic |
| 6.94 × 8 in (176 × 203 mm) | Over 12 mm | 1,093 mm | 1 | Any material, including 3 mm wood and acrylic |
| 10.42 × 12 in (265 × 305 mm) | Over 18 mm | 1,640 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
