Layered coal miner in eight colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Eight layers to stack: a black backing a little larger than the figure, navy coveralls, yellow bands, the face and hands, dark boots and pick head, a wooden handle, a pale helmet and pail, and a yellow lamp.
What is in the file
| Size | 99 × 100 mm (3.9 × 3.94 in), scales to any size |
|---|---|
| Pieces | 15 separate pieces |
| Outlines to cut | 22: 15 outer edges and 7 cut-outs |
| Cut length | 1,723 mm at this size |
| Narrowest part | 5.7 mm at this size |
| Nodes | 249 curve and line segments |
| Layers | 8: backing, coveralls, bands, skin, boots and pick head, handle, helmet and pail and lamp |
Measured from the file. PNG: 1,983 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.99 × 1 in (25 × 25 mm) | 1.4 mm | 438 mm | 100 | Vinyl, card and thin sheet |
| 1.98 × 2 in (50 × 51 mm) | 2.9 mm | 875 mm | 25 | Vinyl, card and thin sheet |
| 2.97 × 3 in (76 × 76 mm) | 4.3 mm | 1,313 mm | 9 | Any material, including 3 mm wood and acrylic |
| 3.96 × 4 in (101 × 102 mm) | 5.8 mm | 1,751 mm | 4 | Any material, including 3 mm wood and acrylic |
| 5.95 × 6 in (151 × 152 mm) | 8.7 mm | 2,626 mm | 1 | Any material, including 3 mm wood and acrylic |
| 7.93 × 8 in (201 × 203 mm) | 12 mm | 3,501 mm | 1 | Any material, including 3 mm wood and acrylic |
| 11.89 × 12 in (302 × 305 mm) | 17 mm | 5,252 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
