Checkerboard with draughts pieces SVG
A board set up for a game of draughts, or checkers: twelve red pieces and twelve cream ones on the dark squares, each with a ring cut in it. Three layers: board, red and cream.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 100 mm (3.94 × 3.94 in), scales to any size |
|---|---|
| Pieces | 49 separate pieces |
| Outlines to cut | 105: 49 outer edges and 56 cut-outs |
| Cut length | 3,147 mm at this size |
| Narrowest join | 1.7 mm at this size |
| Nodes | 518 curve and line segments |
| Layers | 3: board, red pieces and cream pieces |
Measured from the file. PNG: 2,000 × 2,000 pixels, transparent. About the three file types.
How fine is it at your size?
Scaling a design scales its finest detail too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest join | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 1 in (25 × 25 mm) | 0.43 mm | 799 mm | 100 | Too fine for most machines |
| 2 × 2 in (51 × 51 mm) | 0.86 mm | 1,599 mm | 25 | Fine detail: vinyl and paper only, weed with care |
| 3 × 3 in (76 × 76 mm) | 1.3 mm | 2,398 mm | 9 | Vinyl, card and thin sheet |
| 4 × 4 in (102 × 102 mm) | 1.7 mm | 3,197 mm | 4 | Vinyl, card and thin sheet |
| 6 × 6 in (152 × 152 mm) | 2.6 mm | 4,796 mm | 1 | Vinyl, card and thin sheet |
| 8 × 8 in (203 × 203 mm) | 3.5 mm | 6,395 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 12 in (305 × 305 mm) | 5.2 mm | 9,592 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest join is the finest detail in the pattern. Below about half a millimetre it is too small to cut and may fill in when printed. How to open the file in Cricut, Silhouette and laser software.
