Layered camera in four colours SVG
Four layers to stack: a charcoal body, a silver top plate and lens ring, a disc of blue glass and a pale glint to finish. No bridges are needed, because each ring is its own piece.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 72 mm (3.94 × 2.82 in), scales to any size |
|---|---|
| Pieces | 5 separate pieces |
| Outlines to cut | 7: 5 outer edges and 2 cut-outs |
| Cut length | 973 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 124 curve and line segments |
| Layers | 4: body, silver, glass and glint |
Measured from the file. PNG: 2,000 × 1,456 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.72 in (25 × 18 mm) | Over 1.5 mm | 247 mm | 130 | Vinyl, card and thin sheet |
| 2 × 1.43 in (51 × 36 mm) | Over 3 mm | 494 mm | 35 | Any material, including 3 mm wood and acrylic |
| 3 × 2.15 in (76 × 55 mm) | Over 4.6 mm | 741 mm | 15 | Any material, including 3 mm wood and acrylic |
| 4 × 2.87 in (102 × 73 mm) | Over 6.1 mm | 989 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 4.3 in (152 × 109 mm) | Over 9.1 mm | 1,483 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 5.74 in (203 × 146 mm) | Over 12 mm | 1,977 mm | 2 | Any material, including 3 mm wood and acrylic |
| 12 × 8.6 in (305 × 219 mm) | Over 18 mm | 2,966 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
