Free bike SVG

Layered bike with a flower basket SVG

Layered bike with a flower basket, in layered colours
Layered bike with a flower basket. The preview is the SVG file itself.

Seven layers: dark wheels and cranks, a teal frame, a brown saddle and grip, green stems, a tan basket, pink flowers and yellow daisy centres. Stack them in that order.

Download SVG PNG DXF

Free for personal and commercial use, no sign-up. What you can do with it.

What is in the file

Size100 × 83 mm (3.94 × 3.26 in), scales to any size
Pieces19 separate pieces
Outlines to cut49: 19 outer edges and 30 cut-outs
Cut length2,151 mm at this size
Narrowest part2 mm at this size
Nodes318 curve and line segments
Layers7: wheels, frame, saddle and grips, stems, basket, flowers and flower centres

Measured from the file. PNG: 2,000 × 1,667 pixels, transparent. About the three file types.

Will it cut at your size?

Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.

Size, width × heightNarrowest partCut lengthFit on a 12 in sheetRule of thumb
1 × 0.83 in (25 × 21 mm)0.51 mm546 mm110Fine detail: vinyl and paper only, weed with care
2 × 1.65 in (51 × 42 mm)1 mm1,093 mm30Vinyl, card and thin sheet
3 × 2.48 in (76 × 63 mm)1.5 mm1,639 mm12Vinyl, card and thin sheet
4 × 3.31 in (102 × 84 mm)2 mm2,185 mm6Vinyl, card and thin sheet
6 × 4.96 in (152 × 126 mm)3 mm3,278 mm2Any material, including 3 mm wood and acrylic
8 × 6.62 in (203 × 168 mm)4.1 mm4,371 mm1Any material, including 3 mm wood and acrylic
12 × 9.92 in (305 × 252 mm)6.1 mm6,556 mm1Any material, including 3 mm wood and acrylic

The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
