Layered window with blue shutters SVG
Eight layers: a cream wall, a white frame, pale blue glass, blue louvred shutters, green stems, a brown window box, red daisy petals and yellow centres. Stack them in that order.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 88 × 100 mm (3.46 × 3.94 in), scales to any size |
|---|---|
| Pieces | 25 separate pieces |
| Outlines to cut | 57: 25 outer edges and 32 cut-outs |
| Cut length | 2,396 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 327 curve and line segments |
| Layers | 8: wall, frame, glass, shutters, stems, box, petals and centres |
Measured from the file. PNG: 1,769 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.88 × 1 in (22 × 25 mm) | Over 1.5 mm | 609 mm | 110 | Vinyl, card and thin sheet |
| 1.76 × 2 in (45 × 51 mm) | Over 3 mm | 1,217 mm | 30 | Any material, including 3 mm wood and acrylic |
| 2.64 × 3 in (67 × 76 mm) | Over 4.6 mm | 1,826 mm | 12 | Any material, including 3 mm wood and acrylic |
| 3.52 × 4 in (89 × 102 mm) | Over 6.1 mm | 2,434 mm | 6 | Any material, including 3 mm wood and acrylic |
| 5.28 × 6 in (134 × 152 mm) | Over 9.1 mm | 3,652 mm | 2 | Any material, including 3 mm wood and acrylic |
| 7.04 × 8 in (179 × 203 mm) | Over 12 mm | 4,869 mm | 1 | Any material, including 3 mm wood and acrylic |
| 10.56 × 12 in (268 × 305 mm) | Over 18 mm | 7,303 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
