Layered respiratory therapist lungs SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Four layers to stack: a dark plum backing a little larger than the lungs, pink lobes, a deep rose windpipe and airways, and four pale rings for the windpipe.
What is in the file
| Size | 91 × 100 mm (3.57 × 3.94 in), scales to any size |
|---|---|
| Pieces | 8 separate pieces |
| Outlines to cut | 8 outlines |
| Cut length | 1,634 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 197 curve and line segments |
| Layers | 4: backing, lungs, airways and rings |
Measured from the file. PNG: 1,823 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.91 × 1 in (23 × 25 mm) | Over 1.5 mm | 415 mm | 110 | Vinyl, card and thin sheet |
| 1.82 × 2 in (46 × 51 mm) | Over 3 mm | 830 mm | 30 | Any material, including 3 mm wood and acrylic |
| 2.72 × 3 in (69 × 76 mm) | Over 4.6 mm | 1,245 mm | 12 | Any material, including 3 mm wood and acrylic |
| 3.63 × 4 in (92 × 102 mm) | Over 6.1 mm | 1,660 mm | 6 | Any material, including 3 mm wood and acrylic |
| 5.45 × 6 in (138 × 152 mm) | Over 9.1 mm | 2,490 mm | 2 | Any material, including 3 mm wood and acrylic |
| 7.26 × 8 in (185 × 203 mm) | Over 12 mm | 3,320 mm | 1 | Any material, including 3 mm wood and acrylic |
| 10.9 × 12 in (277 × 305 mm) | Over 18 mm | 4,980 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
