Layered math calculator in five colours SVG
Which one? SVG for Cricut and lasers, DXF for the free Silhouette Studio, PNG to print.
Free for personal and commercial use, no sign-up. What you can do with it.
Five layers to stack, tipped to one side: a charcoal body, a pale green display, light grey keys, four orange keys down the side and the four signs in white on top of them.
What is in the file
| Size | 76 × 100 mm (2.99 × 3.94 in), scales to any size |
|---|---|
| Pieces | 24 separate pieces |
| Outlines to cut | 24 outlines |
| Cut length | 1,188 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 204 curve and line segments |
| Layers | 5: body, display, keys, sign keys and signs |
Measured from the file. PNG: 1,537 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 0.76 × 1 in (19 × 25 mm) | Over 1.5 mm | 302 mm | 120 | Vinyl, card and thin sheet |
| 1.52 × 2 in (39 × 51 mm) | Over 3 mm | 604 mm | 35 | Any material, including 3 mm wood and acrylic |
| 2.28 × 3 in (58 × 76 mm) | Over 4.6 mm | 905 mm | 12 | Any material, including 3 mm wood and acrylic |
| 3.04 × 4 in (77 × 102 mm) | Over 6.1 mm | 1,207 mm | 6 | Any material, including 3 mm wood and acrylic |
| 4.55 × 6 in (116 × 152 mm) | Over 9.1 mm | 1,811 mm | 2 | Any material, including 3 mm wood and acrylic |
| 6.07 × 8 in (154 × 203 mm) | Over 12 mm | 2,414 mm | 1 | Any material, including 3 mm wood and acrylic |
| 9.11 × 12 in (231 × 305 mm) | Over 18 mm | 3,621 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
