Varsity letter H SVG
A block H in three stacked layers, dark, light and a colour, each a little smaller than the one below: the look of a sewn letter on a team jacket. Three pieces of vinyl or felt.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 98 mm (3.94 × 3.84 in), scales to any size |
|---|---|
| Pieces | 3 separate pieces |
| Outlines to cut | 7: 3 outer edges and 4 cut-outs |
| Cut length | 1,448 mm at this size |
| Narrowest part | Nothing narrower than 6 mm at this size |
| Nodes | 68 curve and line segments |
| Layers | 3: outline, border and letter |
Measured from the file. PNG: 2,000 × 1,954 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.98 in (25 × 25 mm) | Over 1.5 mm | 368 mm | 100 | Vinyl, card and thin sheet |
| 2 × 1.95 in (51 × 50 mm) | Over 3 mm | 736 mm | 25 | Any material, including 3 mm wood and acrylic |
| 3 × 2.93 in (76 × 74 mm) | Over 4.6 mm | 1,103 mm | 9 | Any material, including 3 mm wood and acrylic |
| 4 × 3.9 in (102 × 99 mm) | Over 6.1 mm | 1,471 mm | 4 | Any material, including 3 mm wood and acrylic |
| 6 × 5.86 in (152 × 149 mm) | Over 9.1 mm | 2,207 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 7.81 in (203 × 198 mm) | Over 12 mm | 2,942 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 11.71 in (305 × 297 mm) | Over 18 mm | 4,414 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
