Layered compass rose in two colours SVG
Two layers: a solid navy rose of sixteen points on a broad ring, and gold pieces for the lit half of every point and the face of the ring.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 100 mm (3.94 × 3.94 in), scales to any size |
|---|---|
| Pieces | 21 separate pieces |
| Outlines to cut | 29: 21 outer edges and 8 cut-outs |
| Cut length | 1,904 mm at this size |
| Narrowest part | 5 mm at this size |
| Nodes | 148 curve and line segments |
| Symmetry | 4-fold rotation |
| Layers | 2: layer 1 rose and layer 2 highlights |
Measured from the file. PNG: 2,000 × 2,000 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 1 in (25 × 25 mm) | 1.3 mm | 484 mm | 100 | Vinyl, card and thin sheet |
| 2 × 2 in (51 × 51 mm) | 2.5 mm | 967 mm | 25 | Vinyl, card and thin sheet |
| 3 × 3 in (76 × 76 mm) | 3.8 mm | 1,451 mm | 9 | Any material, including 3 mm wood and acrylic |
| 4 × 4 in (102 × 102 mm) | 5.1 mm | 1,934 mm | 4 | Any material, including 3 mm wood and acrylic |
| 6 × 6 in (152 × 152 mm) | 7.6 mm | 2,902 mm | 1 | Any material, including 3 mm wood and acrylic |
| 8 × 8 in (203 × 203 mm) | 10 mm | 3,869 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 12 in (305 × 305 mm) | 15 mm | 5,803 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
