Brain lobes in seven layers SVG
A teaching model to stack: a dark backing, then the frontal, parietal, temporal and occipital lobes, the cerebellum and the brain stem, each in its own colour with a dark line showing between them.
Free for personal and commercial use, no sign-up. What you can do with it.
What is in the file
| Size | 100 × 95 mm (3.94 × 3.73 in), scales to any size |
|---|---|
| Pieces | 7 separate pieces |
| Outlines to cut | 9: 7 outer edges and 2 cut-outs |
| Cut length | 1,195 mm at this size |
| Narrowest part | 5.6 mm at this size |
| Nodes | 312 curve and line segments |
| Layers | 7: layer 1 backing, layer 2 frontal lobe, layer 3 parietal lobe, layer 4 temporal lobe, layer 5 occipital lobe, layer 6 cerebellum and layer 7 brain stem |
Measured from the file. PNG: 2,000 × 1,900 pixels, transparent. About the three file types.
Will it cut at your size?
Scaling a design scales its thinnest part too. Here is this one at seven sizes, from 1 to 12 inches on its longer side, with how many copies fit a 12 × 12 inch sheet or mat.
| Size, width × height | Narrowest part | Cut length | Fit on a 12 in sheet | Rule of thumb |
|---|---|---|---|---|
| 1 × 0.95 in (25 × 24 mm) | 1.4 mm | 304 mm | 100 | Vinyl, card and thin sheet |
| 2 × 1.9 in (51 × 48 mm) | 2.8 mm | 607 mm | 25 | Vinyl, card and thin sheet |
| 3 × 2.84 in (76 × 72 mm) | 4.3 mm | 911 mm | 12 | Any material, including 3 mm wood and acrylic |
| 4 × 3.79 in (102 × 96 mm) | 5.7 mm | 1,214 mm | 6 | Any material, including 3 mm wood and acrylic |
| 6 × 5.69 in (152 × 144 mm) | 8.5 mm | 1,821 mm | 2 | Any material, including 3 mm wood and acrylic |
| 8 × 7.58 in (203 × 193 mm) | 11 mm | 2,428 mm | 1 | Any material, including 3 mm wood and acrylic |
| 12 × 11.38 in (305 × 289 mm) | 17 mm | 3,642 mm | 1 | Any material, including 3 mm wood and acrylic |
The narrowest part is the thinnest neck that holds the design together; sharp tips are not counted. For wood and acrylic, keep it at least as wide as the sheet is thick. How to open the file in Cricut, Silhouette and laser software.
